PPM-DT7E

模型 PPM-DT7E
类型 工业级高流量紫外线消毒器
工作电压 直流12伏/24伏
功耗 2.2瓦
UVC辐射功率 180-210毫瓦
UVC波长 270-280纳米
流速 5.0 – 5.1 升/分钟
水连接 1/4英寸或3/8英寸快速接头
房屋材料 铝合金(不锈钢喷嘴)
生命周期(L70) > 10,000 小时
工作压力 0.1 – 0.6 兆帕

Datasheet

Please click the button below to download the complete product datasheet (PDF format).

📄 product datasheet

Description

PPM-DT7E

The flagship powerhouse of the DT7 series. Delivering a massive 5.1 L/min flow rate and an incredible 180-210mW of UVC power, the PPM-DT7E is a true industrial-grade "metal beast." Engineered with stainless steel nozzles and a premium aluminum housing, it is built for the most demanding commercial and whole-house water purification systems.

  • Massive 5.1 L/min Flow Rate: Designed for industrial-level throughput, this sterilizer handles high-volume water flow without compromising sterilization efficiency.
  • Ultimate 180-210mW UVC Output: Packed with the highest power output in its class, it guarantees 99.99% instant sterilization even at extreme flow speeds.
  • Stainless Steel Nozzles & Premium Aluminum Housing: Features durable stainless steel water connections and an anodized aluminum body, offering superior resistance to corrosion, pressure, and extreme heat.
  • Universal 12/24V Auto-Detect: Automatically adapts to both DC 12V and 24V inputs, making it easy to deploy across various international markets without supply chain complexity.

Typical Applications

Industrial Water Treatment

Industrial & Large-Scale Water Treatment

Whole-House Main Line Purification

Whole-House Main Line Purification

Large Commercial HVAC System

Large Commercial & HVAC Water Systems

Additional information

Wavelength

270 – 280 nm

Operating Voltage

DC 12V/24V

Disinfection Rate

99.99%

Water Connection

1/4" or 3/8" Quick Connect

Flow Rate

5.0 – 5.1 L/min

Radiant Power

180 – 210 mW
